Description
Part Name: Diesel Generator Sets Control PCB Board 650-091
1 |
Layers |
1-30 layers |
2 |
Max. Board size |
2000×610mm |
3 |
Min. line Width/Space |
0.075mm(3mil) |
4 |
Max. Copper thickness |
6OZ |
5 |
Min. S/M Pitch |
0.075mm(3mil) |
6 |
Min. hole size |
0.1mm(4mil) |
7 |
Hole Positon |
+/-0.075mm(3mil) CNC Driling |
8 |
Hole dia. Tolerance (NPTH) |
+0/-0.05mm(2mil) |
9 |
Insulation Resistance |
10Kohm-20Mohm |
10 |
Outline tolerance |
±0.10mm(4mil) |
11 |
Twist & Bent |
0.75% |
12 |
Insulation Resistance |
>1012 Ω Normal |
13 |
Electric strength |
>1.3kv/mm |
14 |
S/M abrasion |
>6H |
15 |
Surface Finish |
HASL(LF), Gold plating, Electroless nickel immersion gold, Immersion Tin, OSP(Entek) |
16 |
Solder Mask |
Green/Black/White/Red/Blue/Yellow |
17 |
Panel Size |
110×100mm(min);660×600mm(max) |
18 |
Test Voltage |
10-300V |
19 |
Thermal stress |
288°C 20Sec |
20 |
Min. blind/buried via |
0.15mm (6mil) |
21 |
Surface Finished |
HAL, ENIG, ImAg, Imsn OSP, Plating AG, Plating gold |
22 |
Materials |
FR4,H-TG,Teflon,Rogers,Ceramics,Aluminium, Copper base |
