GAVR 8A automatic voltage regulator avr model for generator
Description
GAVR-8A
Input
Sensing Voltage
220/400VAC,1phase 2wire
Power Voltage
180~240VAC, 1phase 2wire
Voltage Jumper selectable
95-132V ac or 190-264 Hz nominal
Frequency
50-60 Hz nominal
Output
Voltage max
90V dc at 207V ac input
Current continuous
2A dc
Current intermittent
5A for 10 secs
Resistance
20 ohms minimum
Voltage Build-up
esidualvolts at AVR teminal>5VAC
External volts adjustment
+/-7%with 1KΩ 1watt trimmer
Unit Power Dissipation
Max.8Watt
Under Frequency Protection
60Hz system presets knee point at 57Hz
Factory Settings
50Hz system presets knee point at 47Hz
Body size
15.7*11.5*6cm
Application
Biogas Power Generation
Natural Gas Power
Field Engineering
Electric Power
Factory
Fire-fighting
Payment Term
1.We accept T/T,West Union,Money Gram, Cash.
2.All major Credit cards are accepted through secure payment processor ESCROW.
3:Begin to Ready the goods after receiving the 30% down payment, the balance payment before shipment.
Shipment Term
1. We Ship to Worldwide, except APO/FPO.
2: We cooperate with the lots air line, can send the goods by air with competitive freight.
3: For the urgently or small order, can send by express.
Guarantee
1. Guarantee:365 days after selled.
2. During guarantee,the items share free repairs or replacement.
3. Customer is responsible for the freight come-and-go,and the custom tax.
4. You may consider to send the defective item with a economical way,and we send back the repaired items with your new order together.
5. To save the cost,pls send the item back without packing.
6. Pls provide the defective appearance and related invoice number.
Material and Technology
Material and Technology
Polyester capacitor
Semiconductor power devices
All imported IC power devices, high-current model with the United States
Main power resistors
Adjusting potentiometer
U.S. BOURNS original
Chip capacitors
Xiamen Farah
Glue
PU environmental protection, at the same time does not change the electrical properties of high-temperature and high-temperature characteristics
More advantages
1.After the the strict fully functional and performance testing, and high-temperature aging, each batch of test reliability ratio of 3%. The parameters of each board are rigorously tested and adjusted, fully compatible with original products
2.High stability of the key components of the product, we use a low temperature coefficient components to ensure product
3.Original two transistor, and 2 ounces of large-current circuit board (the majority of the conventional circuit board is 1 ounce) to ensure high reliability in a high-power semiconductor element
